Stationary UV dryer
Beltrostat
Application:
The Beltrostat UV dryer is utilised for uniform drying and hardening of UV paintwork and varnishes and is particularly suitable for use in the production of small series, for repairs and in laboratory operation.
The device is optionally equipped with a timer with function buttons or a BELTROMAT control computer.
Design:
Stationary UV dryer for small series, repairs and laboratory operation with drawer.
No device pre-heating due to optimised air flow, even with longer drying times. Uniform, optimised illumination.
Safety lock against accidental opening of the drying chamber during the curing process. Control by timer and function keys. Low-power consumption due to 50% power reduction. Electric shutter - therefore no compressed air required.
Scope of Supply:
- Stationary UV dryer with drawer
- Unit dimensions: 570 x 570 x 460 mm (W x D x H)
- Drawer dimensions: 495 x 540 x 90 mm
- Drawer extension: > 500 mm
- 3m power cable
Optional:
BELTROMAT control computer
Details Beltron high-performance
Stationary UV dryer Beltrostat:
+ Cooling system
+ Control
+ Drawer
Details BELTRON
Stationary UV dryer Beltrostat Details of our
high-performance
Stationary UV dryer Beltrostat
BELTRON Stationary UV dryer Beltrostat are used successfully in:
+ electronic industry
+ textile industry
+ packaging industry
applications BELTRON
Stationary UV dryer Beltrostat
Uses of our
high-performance
Stationary UV dryer Beltrostat
Beltron UV dryers have many key benefits for you and your production, take advantage of our quality benefits:
+ Over 55 Years of quality "Made in Germany"
+ Innovative UV technology
+ Complete, uniform UV hardening
+ Very short hardening times
+ Sustainable energy saving systems
+ Additional processing immediately possible
+ Highly scratch-resistant and glossy
+ Durable & increased chemical resistance
advantage BELTRON
Stationary UV dryer Beltrostat Advantages of our
high-performance
Stationary UV dryer Beltrostat
Control
Cooling system
Drawer
Cooling system
- standard
Control
- Beltromat 8100 with UV Photocell to display the UV power in % and automatic compensation of the exposure times (lamp aging)
Drawer
- Drawer 495 x 540 x 90 mm (B x H x T)
- Drawer unloading > 500 mm
- Irradiated area approximately 210 x 290 mm (DIN A4)
+
Stationary UV dryer Beltrostat
Detail 1
+
Stationary UV dryer Beltrostat
Detail 2
+
Stationary UV dryer Beltrostat
Detail 3
+
Stationary UV dryer Beltrostat
Detail 4
Our Technology and Sales-Partner in Electronic Industry
ahk GmbH · Gewerbering 8 - 13 · 74193 Schwaigern · Germany
Tel.: +49 (0)7138 - 81274-0 · Fax: +49 (0)7138 - 81274-10
Email: info@ahk-service.de · Internet: www.ahk-service.de
Fuses: (F1/F2) 8 A inertia
Voltage supply: 230 V / 50 Hz
Radiant emitter doping: Hg (Mercury)
Radiant emitter power: 800 W
Irradiation surface area: approx. 210 x 290 mm (DIN A4)
Dimensions: 570 x 570 x 460 mm (WxHxD)
Supply voltage: 230 V / 50 Hz
Connection power maximum: approx. 850 W
CE-Sign
The Stationary UV dryer Beltrostat are used successfully in:
These are just a few examples from the various partner portfolio of Beltron.
- electronic industry
- textile industry
- packaging industry
Advice to Stationary UV dryer Beltrostat:
Phone: +49 6074 - 89199-0 or E-Mail: info@beltron.de
Contactform - Stationary UV dryer Beltrostat
